Default TRNG - Diary + Load + Save in one item

Diary+ Load+ Save in one item.


note: work fine with the savegame panel


First part : An example of Diary
Firstly, add your Diary in your script. For more information about the Diary, see the description in the reference panel of NG Center.

Code:
Equipment= PUZZLE_ITEM1,1
WindowsFont= 1, Arial, WFF_BOLD+WFF_CENTER_ALIGN+WFF_SHADOW, 40, 1, 2
WindowsFont= 2, Arial, WFF_LEFT_ALIGN, 22, 1, IGNORE
Diary= 1,PUZZLE_ITEM1,LDF_ZOOM_START+LDF_SOUND_EFFECTS, 1, PL_DOUBLE_PAGE, @pages_1_3.txt,1,2
My Diary is on the slot : PUZZLE_ITEM1


Second Part : Add Load and Save functions
Secondly, you have to change type of flag in the Inventory Memory Zone of your item.

Code:
Parameters= PARAM_BIG_NUMBERS,12292

TriggerGroup=	65,$2000, 51, $12,$2000, 51, $13,$2000, 335, $25,$2000, 338, $9

; Set Trigger Type - FLIPEFFECT 51
; Exporting: TRIGGER(18:0) for FLIPEFFECT(51)
; <#> : Keyboard. Disable <&>keyboard command for (E) time
; <&> :  Save the game (special)
; (E) : Forever (use other action/effect to disable it)
; Values to add in script command: $2000, 51, $12

; Set Trigger Type - FLIPEFFECT 51
; Exporting: TRIGGER(19:0) for FLIPEFFECT(51)
; <#> : Keyboard. Disable <&>keyboard command for (E) time
; <&> :  Load the game (special)
; (E) : Forever (use other action/effect to disable it)
; Values to add in script command: $2000, 51, $13

; Set Trigger Type - FLIPEFFECT 335
; Exporting: TRIGGER(37:0) for FLIPEFFECT(335)
; <#> : Variables. Memory. Set the <&>Inventory item as Selected Inventory Memory
; <&> : PUZZLE_ITEM1 ***
; (E) :
; Values to add in script command: $2000, 335, $25

; Set Trigger Type - FLIPEFFECT 338
; Exporting: TRIGGER(9:0) for FLIPEFFECT(338)
; <#> : Variables. Memory. Set in <&>Inventory Memory the (E)Big Number value
; <&> : Type Flags. (4 = USE, 32 = EXAMINE, $1000 = LOAD ect) (Short)
; (E) : Value of Parameters=PARAM_BIG_NUMBERS at index= 0
; Values to add in script command: $2000, 338, $9

GlobalTrigger= 23,IGNORE,GT_ALWAYS,-1,-1,65,-1
*** don't forget to change this flipeffect if PUZZLE_ITEM1 isn't your Diary


Why used 12292 in a PARAM_BIG_NUMBER command???

because you want:
Load Game+Save Game+Use (for the diary) functions assigned at your item.
so you have 4096+8192+4 = 12292
12292 is the value to enter in "Type of Flag" of your item.


The values for type of flags in the Inventory Zone Memory are the following:

----
equip= 10
use= 4
separate= 16
examine= 32
shotgun ammo= 64
crowbow ammo= 128
grenade ammo= 256
uzi ammo= 512
pistols ammo= 1024
revolver ammo= 2048
load game= 4096
save game= 8192

----

Since engine doesn't support value greater than 255 in Trigger Type Window, you're obliged to use a PARAM_BIG_NUMBER command

Third part : Restore Quick saving, when you Press F5/F6
Since "Keyboard. Disable <&>keyboard command for (E) time" remove Load and Save, including quick saving, you can restore quick save function with following commands:

Code:
Globaltrigger=	24, -1,GT_KEYBOARD_CODE,63,-1,66,-1
TriggerGroup=	66,$2000, 53, $13[/I]
; Set Trigger Type - FLIPEFFECT 53
; Exporting: TRIGGER(19:0) for FLIPEFFECT(53)
; <#> : Keyboard. Simulate receivement of <&>keyboard comand in (E) way
; <&> : Load the game (special)
; (E) : Single sending
; Values to add in script command: $2000, 53, $13

Globaltrigger=	25, -1,GT_KEYBOARD_CODE,64,-1,67,-1
TriggerGroup=	67,$2000, 53, $12
; Set Trigger Type - FLIPEFFECT 53
; Exporting: TRIGGER(18:0) for FLIPEFFECT(53)
; <#> : Keyboard. Simulate receivement of <&>keyboard comand in (E) way
; <&> : Save the game (special)
; (E) : Single sending
; Values to add in script command: $2000, 53, $12

Last edited by julien; 20-05-12 at 22:10.
